| Model No. | SF-1300F14XG | SF-1000F14XG | SF-850F14XG | SF-750F14XG |
| WATTAGE | 1300W | 1000W | 850W | 750W |
| 80PLUS® | 20%: 87% ; 50% : 90% ; 100% : 87% (115V Internal Gold) Efficiency | 20%: 87% ; 50% : 90% ; 100% : 87% (115V Internal Gold) Efficiency | 20%: 87% ; 50% : 90% ; 100% : 87% (115V Internal Gold) Efficiency | 20%: 87% ; 50% : 90% ; 100% : 87% (115V Internal Gold) Efficiency |
| Cybenetics Efficiency Level | • Platinum ≥ 89% ~ ＜91% overall efficiency (115V)
• Platinum ≥ 91% ~ ＜93% overall efficiency (230V) | • Platinum ≥ 89% ~ ＜91% overall efficiency (115V)
• Platinum ≥ 91% ~ ＜93% overall efficiency (230V) | • Platinum ≥ 89% ~ ＜91% overall efficiency (115V)
• Platinum ≥ 91% ~ ＜93% overall efficiency (230V) | • Platinum ≥ 89% ~ ＜91% overall efficiency (115V)
• Platinum ≥ 91% ~ ＜93% overall efficiency (230V) |
| Cybenetics Noise Level | | | | |
| Intel Power Design Guide | EPS 12V v2.92 , ATX 3.1 | EPS 12V v2.92 , ATX 3.1 | EPS 12V v2.92 , ATX 3.1 | EPS 12V v2.92 , ATX 3.1 |
| CPU Compatibility | Support All Intel / AMD Multi-Core CPU & ATX / BTX Compatible Motherboards | Support All Intel / AMD Multi-Core CPU & ATX / BTX Compatible Motherboards | Support All Intel / AMD Multi-Core CPU & ATX / BTX Compatible Motherboards | Support All Intel / AMD Multi-Core CPU & ATX / BTX Compatible Motherboards |
| Dimensions | 150mm(L) x 150mm(W) x 86mm(H) | 150mm(L) x 150mm(W) x 86mm(H) | 150mm(L) x 150mm(W) x 86mm(H) | 150mm(L) x 150mm(W) x 86mm(H) |
| Fan Information | Fan Size | 140mm FAN | 140mm FAN | 140mm FAN | 140mm FAN |
| Fan Bearing | Ultra Silent F.D.B. FAN | Ultra Silent F.D.B. FAN | Ultra Silent F.D.B. FAN | Ultra Silent F.D.B. FAN |
| Electrical Features | Frequency | 60 / 50Hz | 60 / 50Hz | 60 / 50Hz | 60 / 50Hz |
| PFC TYPE | Full Range APFC | Full Range APFC | Full Range APFC | Full Range APFC |
| AC Input | 100V-240V | 100V-240V | 100V-240V | 100V-240V |
| Protection | OVP / OCP / OPP / SCP / UVP / OTP / SIP | OVP / OCP / OPP / SCP / UVP / OTP / SIP | OVP / OCP / OPP / SCP / UVP / OTP / SIP | OVP / OCP / OPP / SCP / UVP / OTP / SIP |
| Operating Temperature | Passed 50℃ Hot Testing | Passed 50℃ Hot Testing | Passed 50℃ Hot Testing | Passed 50℃ Hot Testing |
| Cable Information | Modularity | Fully Modular | Fully Modular | Fully Modular | Fully Modular |
| Cable type | Ultra Flexible Ribbon Cables | Ultra Flexible Ribbon Cables | Ultra Flexible Ribbon Cables | Ultra Flexible Ribbon Cables |
| Safety and Environmental | Safety and EMC | cTÜVus / TÜV / CB / CE / FCC / UKCA / RCM / BSMI / RoHS / KCC / EAC / CCC | cTÜVus / TÜV / CB / CE / FCC / UKCA / RCM / BSMI / RoHS / KCC / EAC / CCC | cTÜVus / TÜV / CB / CE / FCC / UKCA / RCM / BSMI / RoHS / KCC / EAC / CCC | cTÜVus / TÜV / CB / CE / FCC / UKCA / RCM / BSMI / RoHS / KCC / EAC / CCC |
| Environmental Compliance | Comply With Energy Star Standard & EuP (Energy Using Products) Regulation | Comply With Energy Star Standard & EuP (Energy Using Products) Regulation | Comply With Energy Star Standard & EuP (Energy Using Products) Regulation | Comply With Energy Star Standard & EuP (Energy Using Products) Regulation |
