| Model No. | SF-1000C12FG | SF-850C12FG | SF-750C12FG | SF-650C12FG |
| WATTAGE | 1000W | 850W | 750W | 650W |
| 80PLUS® | 80 PLUS Gold 115V Input Certified (20%: 87% ; 50% : 90% ; 100% : 87%) | 80 PLUS Gold 115V Input Certified (20%: 87% ; 50% : 90% ; 100% : 87%) | 80 PLUS Gold 115V Input Certified (20%: 87% ; 50% : 90% ; 100% : 87%) | 80 PLUS Gold 115V Input Certified (20%: 87% ; 50% : 90% ; 100% : 87%) |
| Cybenetics Efficiency Level | | | | |
| Cybenetics Noise Level | | | | |
| Intel Power Design Guide | ATX 12V v3.0, EPS 12V v2.92, ATX 3.1 | ATX 12V v3.0, EPS 12V v2.92, ATX 3.1 | ATX 12V v3.0, EPS 12V v2.92, ATX 3.1 | ATX 12V v3.0, EPS 12V v2.92, ATX 3.1 |
| CPU Compatibility | | | | |
| Dimensions | 140mm(L) x 150mm(W) x 86mm(H) | 140mm(L) x 150mm(W) x 86mm(H) | 140mm(L) x 150mm(W) x 86mm(H) | 140mm(L) x 150mm(W) x 86mm(H) |
| Fan Information | Fan Size | 120mm | 120mm | 120mm | 120mm |
| Fan Bearing | F.D.B.(Fluid Dynamic Bearing) | F.D.B.(Fluid Dynamic Bearing) | F.D.B.(Fluid Dynamic Bearing) | F.D.B.(Fluid Dynamic Bearing) |
| Electrical Features | Frequency | 47-63 Hz | 47-63 Hz | 47-63 Hz | 47-63 Hz |
| PFC TYPE | Active PFC | Active PFC | Active PFC | Active PFC |
| AC Input | Full Range(100V-240V) | Full Range(100V-240V) | Full Range(100V-240V) | Full Range(100V-240V) |
| Protection | OVP / OCP / OPP / SCP / OTP | OVP / OCP / OPP / SCP / OTP | OVP / OCP / OPP / SCP / OTP | OVP / OCP / OPP / SCP / OTP |
| Operating Temperature | Passed 40℃ Hot Testing | Passed 40℃ Hot Testing | Passed 40℃ Hot Testing | Passed 40℃ Hot Testing |
| Cable Information | Modularity | Full Modular | Full Modular | Full Modular | Full Modular |
| Cable type | All Ultra Flexible Ribbon Cables | All Ultra Flexible Ribbon Cables | All Ultra Flexible Ribbon Cables | All Ultra Flexible Ribbon Cables |
| Safety and Environmental | Safety and EMC | cTÜVus / TÜV / CB / CE / FCC / UKCA / BSMI / RoHS / EAC / KCC | cTÜVus / TÜV / CB / CE / FCC / UKCA / BSMI / RoHS / EAC / KCC | cTÜVus / TÜV / CB / CE / FCC / UKCA / BSMI / RoHS / EAC / KCC | cTÜVus / TÜV / CB / CE / FCC / UKCA / BSMI / RoHS / EAC / KCC |
| Environmental Compliance | Comply With Energy Star Standard & EuP (Energy Using Products) Regulation | Comply With Energy Star Standard & EuP (Energy Using Products) Regulation | Comply With Energy Star Standard & EuP (Energy Using Products) Regulation | Comply With Energy Star Standard & EuP (Energy Using Products) Regulation |
