COMBAT SG

• ATX 3.1 & PCIe 5.0
• Semi-modular design
• Cybenetics Gold Certified
• 120mm Fluid Dynamic Bearing Fan
• Full Range Auto Voltage Detection Design 100V~240V (Active PFC)
• 100% Japanese Capacitors (Main Board)

WATTAGE

ADD TO INQUIRY ADD TO COMPARE

SPECIFICATION
CABLE

850W

750W

650W

550W

Technical Specifications

Model No.		SF-850C12SG	SF-750C12SG	SF-650C12SG	SF-550C12SG
WATTAGE		850W	750W	650W	550W
80PLUS®
Cybenetics Efficiency Level		Cybenetics Gold 115V Certified(Overall efficiency: ≥ 87% to＜89%) Cybenetics Gold 230V Certified(Overall efficiency: ≥ 89% to＜91%)	Cybenetics Gold 115V Certified(Overall efficiency: ≥ 87% to＜89%) Cybenetics Gold 230V Certified(Overall efficiency: ≥ 89% to＜91%)	Cybenetics Gold 115V Certified(Overall efficiency: ≥ 87% to＜89%) Cybenetics Gold 230V Certified(Overall efficiency: ≥ 89% to＜91%)	Cybenetics Gold 115V Certified(Overall efficiency: ≥ 87% to＜89%) Cybenetics Gold 230V Certified(Overall efficiency: ≥ 89% to＜91%)
Cybenetics Noise Level
Intel Power Design Guide		ATX 12V v3.1, EPS 12V v2.92	ATX 12V v3.1, EPS 12V v2.92	ATX 12V v3.1, EPS 12V v2.92	ATX 12V v3.1, EPS 12V v2.92
CPU Compatibility
Dimensions		140mm (L) x 150mm (W) x 86mm (H)	140mm (L) x 150mm (W) x 86mm (H)	140mm (L) x 150mm (W) x 86mm (H)	140mm (L) x 150mm (W) x 86mm (H)
Fan Information	Fan Size	120mm	120mm	120mm	120mm
Fan Information	Fan Bearing	F.D.B.(Fluid Dynamic Bearing)	F.D.B.(Fluid Dynamic Bearing)	F.D.B.(Fluid Dynamic Bearing)	F.D.B.(Fluid Dynamic Bearing)
Electrical Features	Frequency	47-63 Hz	47-63 Hz	47-63 Hz	47-63 Hz
	PFC TYPE	Active PFC	Active PFC	Active PFC	Active PFC
	AC Input	Full Range(100V-240V)	Full Range(100V-240V)	Full Range(100V-240V)	Full Range(100V-240V)
	Protection	OVP / OCP / OPP / OTP / SCP / UVP / NLO / SIP	OVP / OCP / OPP / OTP / SCP / UVP / NLO / SIP	OVP / OCP / OPP / OTP / SCP / UVP / NLO / SIP	OVP / OCP / OPP / OTP / SCP / UVP / NLO / SIP
	Operating Temperature	Passed 40℃ Hot Testing	Passed 40℃ Hot Testing	Passed 40℃ Hot Testing	Passed 40℃ Hot Testing
Cable Information	Modularity	Semi-modular	Semi-modular	Semi-modular	Semi-modular
Cable Information	Cable type	All Black Ribbon Cables	All Black Ribbon Cables	All Black Ribbon Cables	All Black Ribbon Cables
Safety and Environmental	Safety and EMC	cTÜVus / TÜV / CE / UKCA / FCC / BSMI / RoHS / EAC	cTÜVus / TÜV / CE / UKCA / FCC / BSMI / RoHS / EAC	cTÜVus / TÜV / CE / UKCA / FCC / BSMI / RoHS / EAC	cTÜVus / TÜV / CE / UKCA / FCC / BSMI / RoHS / EAC
Safety and Environmental	Environmental Compliance	Comply With Energy Star Standard & EuP (Energy Using Products) Regulation	Comply With Energy Star Standard & EuP (Energy Using Products) Regulation	Comply With Energy Star Standard & EuP (Energy Using Products) Regulation	Comply With Energy Star Standard & EuP (Energy Using Products) Regulation

model no.: SF-850C12SG
AC INPUT	100-240V 10A 47-63Hz
DC OUTPUT	+3.3V	+5V	+12V	-12V	+5VSB
850W	Max Output Current	20A	20A	70.5A	0.3A	3.0A
Max Combined Wattage	110W	846W	3.6W	15W
850W

model no.: SF-750C12SG
AC INPUT	100-240V 10A 47-63Hz
DC OUTPUT	+3.3V	+5V	+12V	-12V	+5VSB
750W	Max Output Current	20A	20A	62A	0.3A	2.5A
Max Combined Wattage	110W	744W	3.6W	15W
750W

model no.: SF-650C12SG
AC INPUT	100-240V 10A 47-63Hz
DC OUTPUT	+3.3V	+5V	+12V	-12V	+5VSB
650W	Max Output Current	20A	20A	54A	0.3A	2.5A
Max Combined Wattage	110W	648W	3.6W	12.5W
650W

model no.: SF-550C12SG
AC INPUT	100-240V 10A 47-63Hz
DC OUTPUT	+3.3V	+5V	+12V	-12V	+5VSB
550W	Max Output Current	20A	20A	45.5A	0.3A	2.5A
Max Combined Wattage	110W	546W	3.6W	12.5W
550W
