LEADEX III GOLD

• ATX 3.1 & PCIe 5.1(Native 12V-2x6 Cable_1000W & 1300W only)
• Fully modular with all ultra flexible ribbon cables
• 80 PLUS Gold Certified
• Cybenetics Gold Certified
• 140mm Fluid Dynamic Bearing Fan
• Full Range Auto Voltage Detection Design 100V~240V (Active PFC)
• 100% Japanese 105° Capacitors (Main Board)
• Modern Standby Compatible
• Zero RPM with fan ECO Mode.

WATTAGE

ADD TO INQUIRY ADD TO COMPARE

SPECIFICATION
CABLE

1300W

1000W

850W

750W

650W

Technical Specifications

Model No.		SF- 1300F14GE	SF-1000F14GE	SF-850F14GE	SF-750F14GE	SF-650F14GE
WATTAGE		1300W	1000W	850W	750W	650W
80PLUS®		20%: 87% ; 50% : 90% ; 100% : 87% (115V Internal Gold) Efficiency	20%: 87% ; 50% : 90% ; 100% : 87% (115V Internal Gold) Efficiency	20%: 87% ; 50% : 90% ; 100% : 87% (115V Internal Gold) Efficiency	20%: 87% ; 50% : 90% ; 100% : 87% (115V Internal Gold) Efficiency	20%: 87% ; 50% : 90% ; 100% : 87% (115V Internal Gold) Efficiency
Cybenetics Efficiency Level		• Gold ≥ 87% ~ ＜89% overall efficiency (115V) • Gold ≥ 89% ~ ＜91% overall efficiency (230V)	• Gold ≥ 87% ~ ＜89% overall efficiency (115V) • Gold ≥ 89% ~ ＜91% overall efficiency (230V)	• Gold ≥ 87% ~ ＜89% overall efficiency (115V) • Gold ≥ 89% ~ ＜91% overall efficiency (230V)	• Gold ≥ 87% ~ ＜89% overall efficiency (115V) • Gold ≥ 89% ~ ＜91% overall efficiency (230V)	• Gold ≥ 87% ~ ＜89% overall efficiency (115V) • Gold ≥ 89% ~ ＜91% overall efficiency (230V)
Cybenetics Noise Level
Intel Power Design Guide		EPS 12V v2.92 , ATX 3.1	EPS 12V v2.92 , ATX 3.1	EPS 12V v2.92 , ATX 3.1	EPS 12V v2.92 , ATX 3.1	EPS 12V v2.92 , ATX 3.1
CPU Compatibility		Support All Intel / AMD Multi-Core CPU & ATX / BTX Compatible Motherboards	Support All Intel / AMD Multi-Core CPU & ATX / BTX Compatible Motherboards	Support All Intel / AMD Multi-Core CPU & ATX / BTX Compatible Motherboards	Support All Intel / AMD Multi-Core CPU & ATX / BTX Compatible Motherboards	Support All Intel / AMD Multi-Core CPU & ATX / BTX Compatible Motherboards
Dimensions		150mm(D) x 150mm(W) x 86mm(H)	150mm(D) x 150mm(W) x 86mm(H)	150mm(D) x 150mm(W) x 86mm(H)	150mm(D) x 150mm(W) x 86mm(H)	150mm(D) x 150mm(W) x 86mm(H)
Fan Information	Fan Size	140mm FAN	140mm FAN	140mm FAN	140mm FAN	140mm FAN
Fan Information	Fan Bearing	Ultra Silent F.D.B. FAN	Ultra Silent F.D.B. FAN	Ultra Silent F.D.B. FAN	Ultra Silent F.D.B. FAN	Ultra Silent F.D.B. FAN
Electrical Features	Frequency	60 / 50Hz	60 / 50Hz	60 / 50Hz	60 / 50Hz	60 / 50Hz
	PFC TYPE	Full Range APFC	Full Range APFC	Full Range APFC	Full Range APFC	Full Range APFC
	AC Input	100V~240V	100V~240V	100V~240V	100V~240V	100V~240V
	Protection	OVP / OCP / OPP / SCP / UVP / OTP / SIP	OVP / OCP / OPP / SCP / UVP / OTP / SIP	OVP / OCP / OPP / SCP / UVP / OTP / SIP	OVP / OCP / OPP / SCP / UVP / OTP / SIP	OVP / OCP / OPP / SCP / UVP / OTP / SIP
	Operating Temperature	Passed 50℃ Hot Testing	Passed 50℃ Hot Testing	Passed 50℃ Hot Testing	Passed 50℃ Hot Testing	Passed 50℃ Hot Testing
Cable Information	Modularity	Fully Modular	Fully Modular	Fully Modular	Fully Modular	Fully Modular
Cable Information	Cable type	Ultra Flexible Ribbon Cables	Ultra Flexible Ribbon Cables	Ultra Flexible Ribbon Cables	Ultra Flexible Ribbon Cables	Ultra Flexible Ribbon Cables
Safety and Environmental	Safety and EMC
Safety and Environmental	Environmental Compliance	Lead-free Green Materials with RoHS / WEEE Compliance	Lead-free Green Materials with RoHS / WEEE Compliance	Lead-free Green Materials with RoHS / WEEE Compliance	Lead-free Green Materials with RoHS / WEEE Compliance	Lead-free Green Materials with RoHS / WEEE Compliance

model no.: SF-1300F14GE
AC INPUT	100-240V~ 15A 60Hz/50Hz
DC OUTPUT	+3.3V	+5V	+12V	-12V	+5VSB
1300W	Max Output Current	20A	20A	108.3A	0.5A	3.0A
Max Combined Wattage	100W	1299.6W	6W	15W
1300W

model no.: SF-1000F14PGE
AC INPUT	100-240V~ 15A 60Hz/50Hz
DC OUTPUT	+3.3V	+5V	+12V	-12V	+5VSB
1000W	Max Output Current	20A	20A	83.3A	0.5A	3.0A
Max Combined Wattage	100W	999.6W	6W	15W
1000W


AC INPUT	100-240V~ 10A 60Hz/50Hz
DC OUTPUT	+3.3V	+5V	+12V	-12V	+5VSB
850W	Max Output Current	20A	20A	70.8A	0.5A	3.0A
Max Combined Wattage	100W	849.6W	6W	15W
850W

model no.: SF-750F14GE
AC INPUT	100-240V~ 10A 60Hz/50Hz
DC OUTPUT	+3.3V	+5V	+12V	-12V	+5VSB
750W	Max Output Current	20A	20A	62.4A	0.5A	3.0A
Max Combined Wattage	100W	748.8W	6W	15W
750W

model no.: SF-650F14GE
AC INPUT	100-240V~ 10A 60Hz/50Hz
DC OUTPUT	+3.3V	+5V	+12V	-12V	+5VSB
650W	Max Output Current	20A	20A	54.1A	0.5A	3.0A
Max Combined Wattage	100W	649.2W	6W	15W
650W
