VGA 12+4PIN OCP Dongle

Material: 350 gsm grey-backed paperboard + scratch-resistant matte lamination + glued box construction
Color: Solid black
Dimensions: 321 × 55 × 32 mm (Tolerance: ±1 mm)
Overall Dimensions: 413 × 189 mm (Tolerance: ±3 mm)

ADD TO INQUIRY

OVERVIEW
CABLE

SEE IT. HEAR IT. STAY AWARE.

When abnormal current is detected, ARGB lighting and an integrated buzzer deliver synchronized visual and audible alerts, keeping you informed the moment an issue arises.

PRECISE MONITORING. INSTANT ALERTS.

Continuously monitors VGA current and immediately alerts you when abnormal current levels are detected, helping you stay ahead of potential power issues.

RIGHT CONNECTION. RELIABLE PROTECTION.

Clearly marked PSU input and VGA output connections help ensure correct installation and proper power flow, supporting reliable current monitoring for your graphics card.

Over Current Alert System
Current Threshold	Activation Criteria	Alert Response	Suggested Actions
<9.5A	CURRENT FEEDBACK MAINTAINED FOR 10 SECONDS	LED Indicator: ARGB Color Cycling Indicates NORMAL Operation	-
9.5A ~ 12A	CURRENT FEEDBACK MAINTAINED FOR 10 SECONDS	The LED indicator turns ORANGE, and the buzzer emits rapid short beeps until the current returns to normal. Once the current returns to normal, the buzzer stops and the LED resumes its normal ARGB color cycle, indicating that the system has returned to normal operation.	-
Current Difference Between Any Two +12V Lines > 6A	CURRENT FEEDBACK MAINTAINED FOR 10 SECONDS	The LED indicator turns ORANGE, and the buzzer emits rapid short beeps until the current returns to normal. Once the current returns to normal, the buzzer stops and the LED resumes its normal ARGB color cycle, indicating that the system has returned to normal operation.	-
>12A	CURRENT FEEDBACK MAINTAINED FOR 10 SECONDS	The LED indicator flashes RED, and the buzzer emits a continuous tone for 180 seconds. After 180 seconds, the LED remains solid red for an additional 15 seconds, after which VGA Black Screen Protection is triggered. Even if the current returns to normal during this sequence, the warning state and VGA black screen mode remain active.	Shut down the system and inspect all relevant cables connecting the power supply to the graphics card. Once all connections have been verified, power the system back on.
