| 型號 | SF-1000C12FG | SF-850C12FG | SF-750C12FG | SF-650C12FG |
| 瓦數 | 1000W | 850W | 750W | 650W |
| 80PLUS®認證 | 80 PLUS Gold 115V Input Certified (20%: 87% ; 50% : 90% ; 100% : 87%) | 80 PLUS Gold 115V Input Certified (20%: 87% ; 50% : 90% ; 100% : 87%) | 80 PLUS Gold 115V Input Certified (20%: 87% ; 50% : 90% ; 100% : 87%) | 80 PLUS Gold 115V Input Certified (20%: 87% ; 50% : 90% ; 100% : 87%) |
| Cybenetics 效率認證 | | | | |
| Cybenetics 噪音認證 | | | | |
| Intel 電源供應器版本 | ATX 12V v3.0, EPS 12V v2.92, ATX 3.1 | ATX 12V v3.0, EPS 12V v2.92, ATX 3.1 | ATX 12V v3.0, EPS 12V v2.92, ATX 3.1 | ATX 12V v3.0, EPS 12V v2.92, ATX 3.1 |
| 相容CPU | | | | |
| 機身尺寸 | 140mm(L) x 150mm(W) x 86mm(H) | 140mm(L) x 150mm(W) x 86mm(H) | 140mm(L) x 150mm(W) x 86mm(H) | 140mm(L) x 150mm(W) x 86mm(H) |
| 風扇規格 | 尺寸 | 120mm | 120mm | 120mm | 120mm |
| 軸承 | F.D.B.(Fluid Dynamic Bearing) | F.D.B.(Fluid Dynamic Bearing) | F.D.B.(Fluid Dynamic Bearing) | F.D.B.(Fluid Dynamic Bearing) |
| 電機特性 | 頻率 | 47-63 Hz | 47-63 Hz | 47-63 Hz | 47-63 Hz |
| PFC類型 | Active PFC | Active PFC | Active PFC | Active PFC |
| AC 輸入 | Full Range(100V-240V) | Full Range(100V-240V) | Full Range(100V-240V) | Full Range(100V-240V) |
| 保護 | OVP / OCP / OPP / SCP / OTP | OVP / OCP / OPP / SCP / OTP | OVP / OCP / OPP / SCP / OTP | OVP / OCP / OPP / SCP / OTP |
| 工作溫度 | Passed 40℃ Hot Testing | Passed 40℃ Hot Testing | Passed 40℃ Hot Testing | Passed 40℃ Hot Testing |
| 使用線材 | 背板模式 | Full Modular | Full Modular | Full Modular | Full Modular |
| 出線材質 | All Ultra Flexible Ribbon Cables | All Ultra Flexible Ribbon Cables | All Ultra Flexible Ribbon Cables | All Ultra Flexible Ribbon Cables |
| 安規與環保認證 | 安規與電磁相容性 | cTÜVus / TÜV / CB / CE / FCC / UKCA / BSMI / RoHS / EAC / KCC | cTÜVus / TÜV / CB / CE / FCC / UKCA / BSMI / RoHS / EAC / KCC | cTÜVus / TÜV / CB / CE / FCC / UKCA / BSMI / RoHS / EAC / KCC | cTÜVus / TÜV / CB / CE / FCC / UKCA / BSMI / RoHS / EAC / KCC |
| 環保認證 | Comply With Energy Star Standard & EuP (Energy Using Products) Regulation | Comply With Energy Star Standard & EuP (Energy Using Products) Regulation | Comply With Energy Star Standard & EuP (Energy Using Products) Regulation | Comply With Energy Star Standard & EuP (Energy Using Products) Regulation |
