| 型號 | SF-850C12SG | SF-750C12SG | SF-650C12SG | SF-550C12SG |
| 瓦數 | 850W | 750W | 650W | 550W |
| 80PLUS®認證 | | | | |
| Cybenetics 效率認證 | Cybenetics Gold 115V Certified(Overall efficiency: ≥ 87% to＜89%)
Cybenetics Gold 230V Certified(Overall efficiency: ≥ 89% to＜91%) | Cybenetics Gold 115V Certified(Overall efficiency: ≥ 87% to＜89%)
Cybenetics Gold 230V Certified(Overall efficiency: ≥ 89% to＜91%) | Cybenetics Gold 115V Certified(Overall efficiency: ≥ 87% to＜89%)
Cybenetics Gold 230V Certified(Overall efficiency: ≥ 89% to＜91%) | Cybenetics Gold 115V Certified(Overall efficiency: ≥ 87% to＜89%)
Cybenetics Gold 230V Certified(Overall efficiency: ≥ 89% to＜91%) |
| Cybenetics 噪音認證 | | | | |
| Intel 電源供應器版本 | ATX 12V v3.1, EPS 12V v2.92 | ATX 12V v3.1, EPS 12V v2.92 | ATX 12V v3.1, EPS 12V v2.92 | ATX 12V v3.1, EPS 12V v2.92 |
| 相容CPU | | | | |
| 機身尺寸 | 140mm (L) x 150mm (W) x 86mm (H) | 140mm (L) x 150mm (W) x 86mm (H) | 140mm (L) x 150mm (W) x 86mm (H) | 140mm (L) x 150mm (W) x 86mm (H) |
| 風扇規格 | 尺寸 | 120mm | 120mm | 120mm | 120mm |
| 軸承 | F.D.B.(Fluid Dynamic Bearing) | F.D.B.(Fluid Dynamic Bearing) | F.D.B.(Fluid Dynamic Bearing) | F.D.B.(Fluid Dynamic Bearing) |
| 電機特性 | 頻率 | 47-63 Hz | 47-63 Hz | 47-63 Hz | 47-63 Hz |
| PFC類型 | Active PFC | Active PFC | Active PFC | Active PFC |
| AC 輸入 | Full Range(100V-240V) | Full Range(100V-240V) | Full Range(100V-240V) | Full Range(100V-240V) |
| 保護 | OVP / OCP / OPP / OTP / SCP / UVP / NLO / SIP | OVP / OCP / OPP / OTP / SCP / UVP / NLO / SIP | OVP / OCP / OPP / OTP / SCP / UVP / NLO / SIP | OVP / OCP / OPP / OTP / SCP / UVP / NLO / SIP |
| 工作溫度 | Passed 40℃ Hot Testing | Passed 40℃ Hot Testing | Passed 40℃ Hot Testing | Passed 40℃ Hot Testing |
| 使用線材 | 背板模式 | Semi-modular | Semi-modular | Semi-modular | Semi-modular |
| 出線材質 | All Black Ribbon Cables | All Black Ribbon Cables | All Black Ribbon Cables | All Black Ribbon Cables |
| 安規與環保認證 | 安規與電磁相容性 | cTÜVus / TÜV / CE / UKCA / FCC / BSMI / RoHS / EAC | cTÜVus / TÜV / CE / UKCA / FCC / BSMI / RoHS / EAC | cTÜVus / TÜV / CE / UKCA / FCC / BSMI / RoHS / EAC | cTÜVus / TÜV / CE / UKCA / FCC / BSMI / RoHS / EAC |
| 環保認證 | Comply With Energy Star Standard & EuP (Energy Using Products) Regulation | Comply With Energy Star Standard & EuP (Energy Using Products) Regulation | Comply With Energy Star Standard & EuP (Energy Using Products) Regulation | Comply With Energy Star Standard & EuP (Energy Using Products) Regulation |
