LEADEX III PLATINUM

ATX 3.1 & PCIe 5.1（原生 12V-2x6 電源線）
全模組化設計，配備超柔韌扁平線纜
Cybenetics 白金認證
140mm 液壓軸承風扇
全範圍自動電壓偵測設計 100V~240V（主動式 PFC）
100% 日系 105°C 電容（主機板）
相容於現代待機模式
風扇 ECO 模式下零轉速

瓦數

加入洽詢加入比較

概覽
規格
線材

1300W

1000W

850W

750W

1300W

1000W

850W

750W

技術規格

型號		SF-1300F14PE	SF-1000F14PE	SF-850F14PE	SF-750F14PE
瓦數		1300W	1000W	850W	750W
80PLUS®認證
Cybenetics 效率認證		• Platinum ≥ 89% ~ ＜91% overall efficiency (115V) • Platinum ≥ 91% ~ ＜93% overall efficiency (230V)	• Platinum ≥ 89% ~ ＜91% overall efficiency (115V) • Platinum ≥ 91% ~ ＜93% overall efficiency (230V)	• Platinum ≥ 89% ~ ＜91% overall efficiency (115V) • Platinum ≥ 91% ~ ＜93% overall efficiency (230V)	• Platinum ≥ 89% ~ ＜91% overall efficiency (115V) • Platinum ≥ 91% ~ ＜93% overall efficiency (230V)
Cybenetics 噪音認證
Intel 電源供應器版本		EPS 12V v2.92 , ATX 3.1	EPS 12V v2.92 , ATX 3.1	EPS 12V v2.92 , ATX 3.1	EPS 12V v2.92 , ATX 3.1
相容CPU		Support All Intel / AMD Multi-Core CPU & ATX / BTX Compatible Motherboards	Support All Intel / AMD Multi-Core CPU & ATX / BTX Compatible Motherboards	Support All Intel / AMD Multi-Core CPU & ATX / BTX Compatible Motherboards	Support All Intel / AMD Multi-Core CPU & ATX / BTX Compatible Motherboards
機身尺寸		150mm(L) x 150mm(W) x 86mm(H)	150mm(L) x 150mm(W) x 86mm(H)	150mm(L) x 150mm(W) x 86mm(H)	150mm(L) x 150mm(W) x 86mm(H)
風扇規格	尺寸	140mm FAN	140mm FAN	140mm FAN	140mm FAN
風扇規格	軸承	H.D.B. FAN	H.D.B. FAN	H.D.B. FAN	H.D.B. FAN
電機特性	頻率	60 / 50Hz	60 / 50Hz	60 / 50Hz	60 / 50Hz
	PFC類型	Full Range APFC	Full Range APFC	Full Range APFC	Full Range APFC
	AC 輸入	100V~240V	100V~240V	100V~240V	100V~240V
	保護	OVP/ OCP / OTP/ SCP / UVP / OPP / SIP	OVP/ OCP / OTP/ SCP / UVP / OPP / SIP	OVP / OCP / OTP / SCP / UVP / OPP / SIP	OVP / OCP / OTP / SCP / UVP / OPP / SIP
	工作溫度	Passed 50℃ Hot Testing	Passed 50℃ Hot Testing	Passed 50℃ Hot Testing	Passed 50℃ Hot Testing
使用線材	背板模式	Fully Modular	Fully Modular	Fully Modular	Fully Modular
使用線材	出線材質	All Ultra Flexible Ribbon Cables	All Ultra Flexible Ribbon Cables	All Ultra Flexible Ribbon Cables	All Ultra Flexible Ribbon Cables
安規與環保認證	安規與電磁相容性	cTÜVus / TÜV / CB / CE / FCC / UKCA / RCM / BSMI / RoHS / KCC / EAC / CCC	cTÜVus / TÜV / CB / CE / FCC / UKCA / RCM / BSMI / RoHS / KCC / EAC / CCC	cTÜVus / TÜV / CB / CE / FCC / UKCA / RCM / BSMI / RoHS / KCC / EAC / CCC	cTÜVus / TÜV / CB / CE / FCC / UKCA / RCM / BSMI / RoHS / KCC / EAC / CCC
安規與環保認證	環保認證	Comply With Energy Star Standard & EuP (Energy Using Products) Regulation	Comply With Energy Star Standard & EuP (Energy Using Products) Regulation	Comply With Energy Star Standard & EuP (Energy Using Products) Regulation	Comply With Energy Star Standard & EuP (Energy Using Products) Regulation
國際條碼				4711213447693 (BK) / 4711213447808 (WH)	4711213447785 (BK) 4711213447792 (WH)

model no.: SF-1300F14PE
AC INPUT	100-240V~ 15A 60Hz/50Hz
DC OUTPUT	+3.3V	+5V	+12V	-12V	+5VSB
1300W	Max Output Current	20A	20A	108.3A	0.5A	2.5A
Max Combined Wattage	100W	1299.6W	6W	12.5W
1300W

model no.: SF-1000F14PE
AC INPUT	100-240V~ 10A 60Hz/50Hz
DC OUTPUT	+3.3V	+5V	+12V	-12V	+5VSB
1000W	Max Output Current	20A	20A	88.3A	0.5A	2.5A
Max Combined Wattage	100W	999.6W	6W	12.5W
1000W

model no.: SF-850F14PE
AC INPUT	100-240V~ 10A 60Hz/50Hz
DC OUTPUT	+3.3V	+5V	+12V	-12V	+5VSB
850W	Max Output Current	20A	20A	70.8A	0.5A	2.5A
Max Combined Wattage	100W	849.6W	6W	12.5W
850W
